Please note that not all the functions may be available simultaneously, due to pin mux limitation of CPU case. We can check if our SoM is compatible with your application, contact us for more information.
Some functions require transceiver or additional circuitry on expansion board.
MIPI-DSI output 4 lane, 1080p60
MIPI-CSI 2 lane 1080p60 input, spec v1.2
In/out audio S/PDIF
SAI interface for external codec audio
I/O PERIPHERALS
Please note that not all the functions may be available simultaneously, due to pin mux limitation of CPU case. We can check if our SoM is compatible with your application, contact us for more information.
Some functions require transceiver or additional circuitry on expansion board.
2 x USB 2.0 OTG
SDIO 3.0 Bus Interface
Up to 5 x UART Interfaces
Up to 2 x LPSPI Interfaces
Up to 4 x I2C Interfaces
Up to 2 x PWM outputs
2 x Ethernet 1Gbps with on-board PHY (optional)
Up to 2 x CAN Bus 2.0B / CAN FD ports
Integrated Secure Element co-processors (optional)
Integrated Temp Sensor (optional)
More GPIOs available & SW configurable (optional)
FRAM (optional)
4 x ADC inputs
SYSTEM
230 pin edge connector
Single +5 VDC ±5% power supply
On board regulators for all integrated functions
Power consumption depends on MPU clock frequency / state.
OPERATING SYSTEMS
Linux (Cortex® – A55 core) + FREERTOS (Cortex® – M33)
SOFTWARE
OS Linux Yocto
Graphic SDK, QT(under responsibility and request from costumer) BSP supported.
TEMPERATURE
These temperatures are the ambient operating temperature ranges for the components used into SoM, with exception of iMX 93 processor, which is specified on junction operating temperature range, 0-95°C for commercial version and -40-105°C for industrial version and -40 to 125° for automotive version. SoM ambient operating temperature depends on the application and on the cooling measures applied.
Some ordering options are not available in automotive version. Contact Elettronica GF for more information.
